Continuous, Intermittent Load - 1min. Work And 4 Min. Rest
Lifting capacity
200 kg distributed load (weight of the patient and equipment + accessories)
Protection Fuses
F1 and F2 (127 or 220V ~) = 5A - delayed action.
Protection Against Harmful Ingress Of Water
IPX 0 - Every chair for exams, except for footswitch And IPx1 - Pedal command
Frequency
60 Hz
Power
220 V ~ ( Internally Selectable )
Structure
Built in solid steel, with anticorrosive treatment and coated in high impact polystyrene, it provides greater security, resistance and durability to the set.
Anti-slip base
No need to fix it on the floor.
Equipped with curved backrest
That besides providing comfort to the patient, it allows greater approach to the operative field.
Integrated foot control
It unifies all the foot controls, allowing drives of the chair, equipment, water unit and reflector.
Integrated junction box
Optimizing space inside the office.
Displays the on/off button
Located on the side of the base of the chair facilitating the access of the professional.
Upholstery
Wide padding, with lumbar support, mounted on a rigid structure covered with high resistance injected polyurethane, coated with laminated material, seamless, non-toxic and anti-flame. Equipped with a wide padding with Easy fix system for a quick and easy removal of the backrest for sanitization
Leather Upholstery
With 05 colors available. (optional)
Massage system
Upholstery with massage system and lumbar support, which provides greater comfort to the patient, minimizing stress and fatigue during the procedures.
Independent command and control that can be triggered by the patient himself.(*optional)
Pneumatic support arm
Folding arm support with rounded finish, dispenses movement and facilitates cleaning and disinfection
A fixed arm and an articulable arm, with a pneumatic device driven through the control panel of the equipment, which allows to control the movement of the arm "drop" facilitating the access of the patient, automatic movement (drop) when the chair reaches the zero position facilitating the exit of the patient.
Joystick command pedal
Three work schedules
Return to zero position
Spit position and return to last position
Blocking the movements of the chair
Reflector activation
Double Crushing Protection System
When the chair is in a downward movement of the seat, any obstruction under the chair will trigger this device, automatically stopping all chair movements, preventing further problems.
The anti crushing system is located at the back of the backrest and at the back of the pantograph and is activated when something prevents the movement of the chair, preventing accidents.
Trendelemburg position
Synchronized movements between the backrest and the seat. At the end of the descent course of the backrest allows the Trendelemburg position (adopted position where the legs and pelvis are at a higher level than the thorax and head).
Lifting system
Electro-mechanical driven gearmotor with soft start.
It provides smoothness in the movements.
Eliminates the sensation of bumps when activated.
Increases engine life.
Electronic System
Integrated and low voltage: 24 volts.
Allows full interface with reflector, equipment and Saevo electronic water unit.
Greater safety to the patient and the professional.
